$86.95
Model Number : J-WP11F-120W-S4W3C
Input Watts : 60/90/100/120W Selectable
Construction
• Housing: Die-cast Aluminum
• Lens: Polycarbonate
• Easy to install and operate.
Electrical
• High efficacy up to 160lm/W
• AC120-277V, 0-10V dimming
• Surge Protection: 6KV
• CCT & Wattage Selectable
• Light Distribution: Type III
• Waterproof: IP65 rated
Applications
• Factory, Warehouse, Walkways, Hallways, Outdoor Commercial, Outdoor Residential
Installation
• Microwave motion sensor and emergency driver available
• Automated Dusk to Dawn photocell functionality
• Wall Mount
• Five 1/2″ knockouts: one on each side for convenient installation
Warranty
• 5 years warranty
| Specs at a Glance | * Nominal Wattage (Switchable) |
|---|---|
| Configuration | J-WP11F-120W-S4W3C |
| Input Voltage | 120-277V |
| Wattage (W)* | 60W / 90W / 100W / 120W Wattage Selectable |
| Lumens (lm) | max. 19200 lm |
| Efficacy (LPW) | Up to 160 lm/W |
| CCT (K) | 3000K / 4000K / 5000K Tunable |
| CRI | >80 |
| Operating Temp | -40°C to +50°C |
| Certification | UL DLC Premium |
| Warranty | 5 year limited warranty |
